Yokogawa CP471 Processor Module GS 33J60E30-01EN in Stock
Maintenance information
On-line replacement of CP471 in dual-redundant configuration can be performed by the user. • For replacement of existing CP461 with CP471. 1. Software version of Control Function for Field Control Station must be R6.05 or later. 2. The style code of ESB bus coupler module EC401 which is used together with CP471 must be S3 or later. 3. Replacement from CP461 to CP471 is prohibited to perform by a user. Replacement work must be done by the service engineer authorized by Yokogawa Electric Corporation. 4. CP471 can not be co-existed with CP461 in dual-redundant configuration. However, a pair of CP461 in dual-redundant configuration can be on-line replaced with a pair of CP471. 5. Existing CP471 must not be replaced with CP461.
Operation condition
These field control units are shipped with processor module CP461. Existing CP461 can be replaced with CP471. *2: For AFV30*,*= 0 and 1 are applicable to only AFV30*-S*****. In CE Marking applicable countries or areas: a) Except for explosion protection purpose - CP471-00 can be mounted on AFV30*-S***0*. - CP471-01 can be mounted on AFV30*-S***1*. b) For the purpose which requires an explosion protection standard. - CP471 cannot be mounted on AFV30-S***0*and -S***1*. In the countries and areas other than CE Marking applicable countries or areas: a) Except for explosion protection purpose - CP471-00 can be mounted on AFV30*-S***0*. - CP471-01 can be mounted on AFV30*-S***1*. b) For the purpose which requires FM NI explosion protection standard. (*) - CP471-10 can be mounted on AFV30-S***0*. - CP471-11 can be mounted on AFV30-S***1*. *: AFV30*-S***0*and -S***1*comply with only FM NI as an explosion protection standard. • CP471 can be combined with the style code S3 or later of ESB bus coupler module EC401.
Processor Module Specificastions
| Description | ||
| Model | CP471 | Processor Module (for AFV30/AFV40/A2FV50/A2FV70) |
| Suffix Codes | 0 | With no explosion protection |
| -1 | With explosion protection | |
| 0 | Basic type | |
| 1 | With ISA Standard G3 option | |
| Option Code | /ERFI | Enhanced RFI (Tokuchu) (*1) |
