1PC GE FANUC IC693PWR321Y

Product Description

TheGE Fanuc IC693PWR321 is a standard power supply. This unit is a 30 watt supply that can use direct or alternating current. It operates on an input voltage of either 120/240 VAC or 125 VDC.Aside from a +5VDC output,this power supply can provide two +24 VDC outputs. One is a relay power output, which is used to power circuits on Series 90-30 Output Relay modules. The other is an isolated output, which is used internally by some modules. It can also provide external power for 24 VDC Input modules.

Just like I/O modules,this power supply is easily compatible with the Series 90-30 system and works with any CPU model.There is a limiting feature on the power supply that protects the hardware by shutting the power off if there is a direct short.The IC693PWR321 has six terminals for user connections. Like all Series 90-30 power supplies, this model is connected to the CPU performance. This enables simplex, fail-safe, and fault tolerance capabilities.The power supply also hasadvanced diagnostics as well as built-in smart switch fusing. This makes for high-performance and increased safety when using the unit.

Note

Previous versions of this power supply had five terminals on the terminal block. The new version (shown above), which has six terminals, is functionally the same as the previous version. The change was made to conform to European EC requirements
