GE Fanuc IS200TBAIH1C POWER SUPPLY

Description

The IS200TBAIH1C printed circuit board is a very long and slim device. The left half of the IS200TBAIH1C is occupied by two (2) black terminal blocks. Each terminal block may contain up to twenty-four terminals which are cube shaped and made from silver metal. These terminals combined for a total of forty-eight terminals which are labeled as one (1) through forty-eight (48). Much of the right edge of the IS200TBAIH1C is taken up by three (3) medium sized connector ports. These connector ports have been arranged vertically on the right of the IS200TBAIH1C. Long lines of electronic components are lined up vertically in the center of the IS200TBAIH1C. Ten (10) potentiometers or variable resistors are spaced out evenly in the IS200TBAIH1C’s center. Four (4) additional potentiometers have been grouped together on the lower right corner of the IS200TBAIH1C. At least nine (9) small black transistors are lined up along the right of the center section of the IS200TBAIH1C. Also positioned in the center of the IS200TBAIH1C is a series of at least twenty (20) red jumpers. Every jumper is being used to connect together at least two (2) small metal jumper pins. This middle section of the IS200TBAIH1C is also covered with many small black rectangular diodes.

Mark VIeIntroduction

Mark* VIe is a flexible control system for multiple applications. It features highspeed, networked I/O for simplex, dual, and triple redundant systems. Industrystandard Ethernet communications are used for I/O, controllers, and supervisory interface to operator and maintenance stations, and third-party systems. ToolboxST* is used for Mark VIe and related controls as a common software platform for programming, configuring I/O, trending, and analyzing diagnostics. It provides a single source of quality, time-coherent data at the controller and plant level for effectively managing equipment assets.
