GE FANUC IC695ALG626 RX3i ANALOG NEW 1 YEAR WARRANTY

Description

The IC695ALG626 is a 16/8 Channel, Non-Isolated, Differential, Voltage/Current, HART, Analog Input module from the GE Fanuc RX3i Series. This module provides 16 single-ended or 8 differential input channels. Module IC695ALG626 has 4 internal HART modems. See specifications for this unit on IC695ALG626's website page

These modules must be located in an RX3i Universal Backplane. They require an RX3i CPU with firmware version 3.5 or later. Machine Edition Version 5.5 or later must be used for configuration. The modules can be used with a Box-style (IC694TBB032), Extended Box-style (IC694TBB132), Spring-style (IC694TBS032), or Extended Spring-style (IC694TBS132) Terminal Block. Extended terminal blocks provide the extra shroud depth needed for shielded wiring. Terminal Blocks are ordered separately
