GE FANUC IC200CHS002 1 YEAR WARRANTY

Description

IC200CHS002 is a Box-Style I/O Carrier manufactured by Ge Fanuc for its VersaMax series.This carrier is comprised of 36 IEC box-style terminals. The IC200CHS002 provides backplane communications, mounting, and field wiring for one input-output module.

The IC200CHS002 has many features including its ability to support wiring for a maximum of 32 input output points plus 4 shared power connections. The carrier is equipped with a set of easily set keying controls to ensure proper installation of the correct module type. Keys are set to match the keying at the basement of the module, and carrier-to-carrier male/female connectors facilitate quick installation of connections at the backplane without the need of additional cables or tools. A module latch hole is used to secure the module to the carrier, and a transparent protective hinged door covers the wiring terminals. An auxiliary input output terminal strip allows the use of additional bussed connection points.

During mounting, theIC200CHS002easily snaps onto a 7.5 mm x 35 mm DIN rail. It is important to electrically ground the DIN rail to provide EMC protection. The rail must have a conductive corrosion-resistant finish, preferably unpainted. For those applications that require maximum resistance to mechanical vibration and shock, the IC200CHS002 must be panel-mounted. During field wiring, each terminal should accommodate one solid /stranded AWG of 14 to AWG of 22 or two wires up to AWG of 18.

FAQ:

1.Is the part new?
Yes, 100% Original brand new

2.How is the package?
Original factory seal packed

3.What is the lead time?
In stock: 1-3 working days

4.What is the MOQ:
1pcs

5.What is the payment term:
TT and Western Union, other negotiable

6.Where the item ship from?
Xiamen

7.What is the warranty time?
One year

8. How to delivery the PLC Parts?
Kindly tell us your address,we check best cost for you
Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
