GE Fanuc F31X134EPRBHG1-FR00/0 Encoder Processor Interface Board

Description

The entire Boiler house plants is controlled and monitored by M/s YOKOGAWA make CENTUM XL DCS system. The DCS system is having 4 numbers of control stations and 4 numbers of Panel operated consoles. Each boiler is controlled and monitored by independent and dedicated control station (EFCD). The Balance of plants like, Dearator, fuel oil system, instruments air system, Boiler feed water pumps, Makeup water pumps, and drinking water pumps, steam distribution headers etc is controlled and monitored by separate control station. Similarly the logic part of the each boiler is taken care by an independent YASAKAWA make U84 PLC and the BOP logic part is controlled by the separated YASAKAWA make U84 PLC. The monitoring of the entire plant isdone through four numbers panel operated consoles, three are in control room and one is located in remote location (Boiler House officer room) which around 400 meters from control room. Refer Annexure I and II for detailed layout of the PLC and DCS system components.

GE Fanuc Produce

Main Products

PLC : Allen Bradley, GE FANUC , Schneider
DCS : ABB , Siemens MOORE , Foxboro , Westinghouse , YOKOGAWA
ESD : Triconex , HIMA , Bently Nevada , ICS Triplex
Excitation cards : ABB , GE Marke
