GE Fanuc IC697MDL753Module 100% Original

Description

The IC697MDL753 is a 5/48 Volt DC, 0.5 Amp, Negative Logic, 32-Point Output module from the GE Fanuc 90-70 Series. This module provides 32 points divided into 2 isolated groups of 16 points each. The rated voltage on this module can be 5 volts DC or 10 to 60 volts DC. It provides a high degree of inrush current at 10 to 60 volts which makes the outputs suitable for a wide range of loads which have such characteristics. It also operates at TTL levels.

The outputs are ideal for a wide spectrum of loads. This is due to the effective delivery of high inrush current which is between 10 to 60 volts. You can spot LED indicators at the top of each logic point of the PLC module. Their primary function is to display the ON-Off status of each logic point of the PLC. Jumpers and DIP switches are not required for the configuration of I/O references located on the module.The configuration of the module is achieved using Microsoft’s MS-DOS or Windows NT & 95 operating systems over the TCP/IP protocol. Programming devices can be either compatible personal computers, PS/2, AT or IBM.

As mentioned earlier, theIC697MDL753 PLCoutput module is compatible with a wide variety of loads which include indicators, motor starters, solenoids and TTL interfaces.Due to the significant overall heat dissipation with each group of modules, the maximum current is set to 4 Amps. Each output can deliver a current rating exceeding its long-term rating. The ability of each output point to deliver a current largely depends on the device’s current rating as well as the duration the device is powered ON. Since the Logic output module has no replaceable fuses, a¾ Amp 250-voltfuse is connected externally to each output point. The fuse models are eitherLittle Fuse 312.750 or Bussmann AGC-3/4.

FAQ:

1.Is the part new?
Yes, 100% Original brand new

2.How is the package?
Original factory seal packed

3.What is the lead time?
In stock: 1-3 working days

4.What is the MOQ:
1pcs

5.What is the payment term:
TT and Western Union, other negotiable

6.Where the item ship from?
Xiamen

7.What is the warranty time?
One year

8. How to delivery the PLC Parts?
Kindly tell us your address,we check best cost for you
Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
