Model Number IS200SRLYH2AAA 100% New Original

Description

The IS200SRLYH2AAA from General Electric is a board component made as part of the Mark VI series. The Mark VI is one of several Speedtronic systems made by GE used for the management of gas and steam turbine systems or other power management systems.

The IS200SRLYH2AAA is one of several terminal boards that is approved for use in hazardous locations.This board is part of a Mark VIe Discrete Output I/O pack that works in conjunction with an IS220PDOA board. The contact outputs on the board have a nominal voltage of 24/48/125 VDC and a max current of 5/1.2/0.6 ADC. The board is a UL E2067685 Class 1 Zone 2 Group IIC board.It is also labeled as an ANSI/ISA-12.12.01-2015 Class I, Division 2, Groups A/B/C/D component.

The IS200SRLYH2AAA is a square circuit board with a number of board components. It is drilled in four corners and is also drilled in several places within the body of the board. Components mounted onto its surface include a terminal strip, a d-shell female connector, and several other connectors.The board also has twelve relays that are lined up on the board in three lines of four.Other board components include capacitors, resistors, and integrated circuits. There are also multiple places on the board marked for metal oxide resistors, but these may not be mounted to the board’s surface.

Warranty

1.If the item is defective upon receipt, it should be within 7days from the date of receipt for exchange a new one (Buyer should return all original and undamaged items under re-saleable condition).

2.We supply free repairing service within one year of purchase. For the first 1 month, we will pay one way shipping cost( from us to your location); After 1 month of purchase, the buyer need to pay two ways of shipping cost.

3.One we get the returned items, we will send the replaced ones back as soon as possible.

4.Our warranty does not extend to any products that are physically damaged or under un-normal operating conditions as a result of misuse or improper installation on the parts
