GE Fanuc IC693CHS392Module New In Stock
Description
The IC693CHS392 expansion baseplate has a 25-pin female D-type I/O Bus Expansion connector that is mounted at its right end.This connector is used for making connections to other baseplates. It has 10 slots labeled serially from 1 to 10. The baseplate cannot stand alone. It must be mounted in a CPU baseplate of a system having a CPU, either in a PLC or in a Personal Computer that has a Personal Computer Interface (PCI) Card. The first expansion baseplate is connected to the CPU’s baseplate via a short parallel cable which provides seamless parallel data transfer between the CPU baseplate and the locally expanded I/O baseplates. The type of the CPU determines the maximum number of Expansion baseplates that can be installed in a system. CPUs 331, 340, and 341 allows a maximum of 4 while CPUs 350 and higher can allow up to 7 baseplates. Power must be supplied to the expansion baseplate and must be calculated based on the baseplate’s modules as well as and the local load that will be placed on each baseplate’s power supply.
