GE Fanuc IS200STAIH2ACB Original And Brand New Module

Description

S-type boards have one I/O pack for simplex and dual redundant systems. They are half the size of T-type boards and are DIN-rail or surface mounted. Two versions of the boards are available, H1 and H3. H1 boards have fixed terminal blocks, and H3 boards have removable terminal blocks. A H2 version is available for mounting of custom blocks such as spring-cage or insulation displacement. S-type boards have box type terminal blocks that accept one 3.0 mm2 (#12AWG) wire or two 2.0 mm2 (#14AWG) wires with 300 V insulation per point. Screw spacing is 5.08 mm (0.2 inch) minimum, center-to-center. A shield strip is provided to the left of each block. It can be connected to a metal base for immediate grounding or floated to allow individual ground wires from each board to be wired to a centralized, cabinet ground strip.Signal flow begins with a sensor connected to a terminal block on a board. There are two types of boards available. T-type boards contain two 24 point, barrier-type, removable, terminal blocks. Each point can accept two 3.0 mm2 (#12AWG) wires with 300 V insulation per point with spade or ring type lugs. In addition, captive clamps are provided for terminating bare wires. Screw spacing is 9.53 mm (0.375 inch) minimum, center-to-center. A shield strip is provided next to each block, which is actually the left-hand side of the metal base where the board is mounted. Wide and narrow boards are arranged in vertical columns of high and low-level wiring that can be accessed from top and/or bottom cable entrances. An example of a wide board is a board that contains magnetic relays with fused circuits for solenoid drivers. T-type boards are normally surface mounted, but can also be DIN-rail mounted.
