GE FanucIS230STTCH2A ModuleFast Delivery
Description
Each rack configuration will accept one power supply in the leftmost module position, and either: 1. seventeen (17) 3rd Party VME modules (with no IC697 modules installed), 2. nine (9) IC697 modules, or 3. a combination of IC697 and 3rd Party VME modules. The power supply capacity may limit the number of modules in a rack. No more than three VME modules can be used in a rack with IC697 modules. The flexibility of these racks to allow both 3rd party VME and IC697 modules is accomplished through the use of jumpers on the backplane to configure slots. The VME Integrator rack is factory configured to accept standard IC697 modules. Integration of 3rd party VME modules is done by moving these jumpers to different positions. The exact jumper configuration depends on the requirements of each 3rd Party VME module. Two racks can be interconnected to share a single power supply for applications having extended I/O requirements. A Power Supply Extension Cable kit (IC697CBL700) is available for such applications. There are also four power cube screw connections (+ 5V, +12V, -12V, 0V) on the backplane. These connections are not intended for direct connection to a 3rd Party power supply. Each rack provides slot sensing for rack-type I/O modules. No jumpers or DIP switches on the I/O modules are required for addressing of these modules. Overall rack dimensions are 11.15” H x 19” W x 7.25” D (283mm x 483mm x 184mm). Slots are 0.8” wide except the power supply slot which is 2.4” wide. The following figures show mounting dimensions for the rear mount (Figure 1) and the front mount (Figure 2) racks.
More About GE Fanuc
IC693CPU363Series 90-30 Module CPU Backplane
IC200PBI001VersaMax I/O Module Profibus Interface Unit
IC693APU300Series 90-30 High Speed Counter Module
IC693MDL730Series 90-30 Output Module 2 Amp Positive Logic 8 Points
IC697CMM711Series 90-70 Communication Coprocessor
IC697BEM731Controller Module Series 90-70 Genius I/O Bus Controller
IC200ALG430VersaMax Analog Mixed Module
IC697PWR711Series90-70 Power Supply Module
IC670MDL640Field Control Input Module
IC693CPU323Series 90-30 CPU Module
IC695CPU310RX3i CPU Module Series
FAQ:
1.Is the part new?
Yes, 100% Original brand new
2.How is the package?
Original factory seal packed
3.What is the lead time?
In stock: 1-3 working days
4.What is the MOQ:
1pcs
5.What is the payment term:
TT and Western Union, other negotiable
6.Where the item ship from?
Xiamen
7.What is the warranty time?
One year
8. How to delivery the PLC Parts?
Kindly tell us your address,we check best cost for you
Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
