GE Fanuc IC660BBA025 Current-Source Analog Input Block

Description

The GE IC660BBA025 is a 24/48 VDC Current-Source Analog Output Block. It features six 4-20mA output circuits and requires no calibration. It is software-configurable with advanced diagnostics and bus switching module control.

Features

1. Six 4-20mA analog output circuits
2. No calibration required for operation
3. Software configurable
4. Advanced diagnostics
5. Dedicated Bus Switching Module control
6. Provides power to all circuits; no separate power is required for 4-20mA signals
7. Output accuracy of 0.15% at 25°C
8. Output resolution of 6μA
9. Configurable features include output hold last state or default, circuit scaling to engineering units values, output feedback checking, and feedback time
10. CPU redundancy
11. Fault reporting can be enabled or disabled circuit-by-circuit
12. Automatic diagnostic checks for output overrange and underrange, and output feedback

1. Size (height x width x depth): 8.83” (22.44cm) x 3.34” (8.48cm) x 3.91” (9.93cm)
2. Weight: 4 lbs. (1.8 kg)
3. LEDs (I/O Block): Unit OK, I/O Enabled
4. Block to Block Isolation: 1500V for one minute
5. Heat Dissipation: 12 Watts maximum
6. Block Power (nominal): 24/48VDC
7. Power supply voltage: 18-56 VDC
8. Maximum current: 600mA
9. Frequency/ripple: 10% max. ripple
10. PS dropout time: 10ms min.
11. Output Specifications: Accurate control of output currents from 0-24mA
