Bently Nevada 3500/23E Transient Data Interface PLC Module

Description

The 3500/23E Transient Data Interface (TDI) is the interface between the 3500 ENCORE monitoring system and GE’s System 1* condition monitoring and diagnostic software. The TDI combines the capability of a System Monitor with the data collection capability of a communication processor. The TDI operates in the System Monitor slot of a 3500 ENCORE rack in conjunction with the vibration monitors (3500/42E) to continuously collect steady state and transient waveform data and pass this data through an Ethernet link to the host software. Static data capture is standard with the TDI, however using an optional Channel Enabling Disk will allow the TDI to capture dynamic or transient data as well. The TDI features improvements in several areas over previous communication processors and incorporates the Communication Processor function within the 3500 ENCORE rack.
