Bently Nevada 3500/60-05-01 New In Stock

Description

The 3500/60 & 61 modules provide six channels of temperature monitoring and accept both Resistance Temperature Detector (RTD) and Thermocouple (TC) temperature inputs. The modules condition these inputs and compare them against user-programmable alarm setpoints. The 3500/60 and 3500/61 provide identical functionality except that the 3500/61 provides recorder outputs for each of its six channels while the 3500/60 does not. The user programs the modules to perform either RTD or TC temperature measurements using the 3500 Rack Configuration Software. Different I/O modules are available in RTD/TC non-isolated or TC isolated versions. The user can configure the RTD/TC non-isolated version to accept either TC or RTD, or a mixture of TC and RTD inputs. The TC isolated version provides 250 Vdc of channel-to-channel isolation to protect against external interference. When used in a Triple Modular Redundant (TMR) configuration, temperature monitors must be installed adjacent to each other in groups of three. When used in this configuration, the system employs two types of voting to ensure accurate operation and to avoid single-point failures.

The primary purpose of the 3500/45 monitor is to provide: 1. Machinery protection by continuously comparing monitored parameters against configured alarm setpoints to drive alarms. 2. Essential machine information for both operations and maintenance personnel. Each channel, depending on configuration, typically conditions its input signal into various parameters called “proportional values”. Alert setpoints can be configured for each active proportional value and Danger setpoints can be configured for any two of the active proportional values.

Ordering Information

The 3500/33 requires 3500 Rack Configuration software, version 3.3 or later

The 3500/33 requires 3500 Data Acquisition software, version 2.40 or later

The 3500/33 requires 3500 Data Display software, version 1.40 or later

When used with a 3500/93 LCD Display module, the 3500/93 will require firmware revision P or later.

When used with a 3500/94 VGA Display module, the 3500/94 will require firmware revision C or later
