Yokogawa SAI143-H45 DCS New Module
Overview
The DC/DC circuit converts the battery voltage of the back plane to 5 VDC, which is supplied to all logical circuits on the board. Should the voltage disappear, a signal is activated in the back plane.
The battery voltage is fused. If the fuse is blown a signal is activated in the back plane. The fuse is accessible on the front panel of the board, and can be used for disconnecting the power.
On the front panel are two green LEDs for indicating 5V power and normal polling.
The control logic is used for decoding the address bus and for generating signals to read/write the status register and read the input buffers.
The address bus, the data bus and the control signals are buffered before entering the board.
The status register is a read/write register. On reset the status is zeroed. Thus it is possible to check the function of the board.
The signals on the inputs are buffered before entering the data bus.
The inputs are divided into six groups, where each group has a common return conductor. The inputs are protected by transient suppressors. Each input is equipped with an LED that is lit when the input is active. These LEDs are not visible from the front panel.
