Yokogawa 0950-3017 PS605-0101 Module New In Stock
Overview
The input board INK-2 is used for getting information about external activities, which can be used, for example, to control other outputs. The INK-2 board is controlled by the alarm processor board LPK-2, via the address and data buses in the back plane. The board also contains a status register for functional checks. The INK-2 board is equipped with 24 opto-isolated inputs for 24 VDC/10 mA. These inputs are divided into six groups, each with four inputs with a common return conductor.
The DC/DC circuit converts the battery voltage of the back plane to 5 VDC, which is supplied to all logical circuits on the board. Should the voltage disappear, a signal is activated in the back plane.
The battery voltage is fused. If the fuse is blown a signal is activated in the back plane. The fuse is accessible on the front panel of the board, and can be used for disconnecting the power.
The control logic is used for decoding the address bus and for generating signals to read/write the status register and read the input buffers.
The address bus, the data bus and the control signals are buffered before entering the board.
The inputs are divided into six groups, where each group has a common return conductor. The inputs are protected by transient suppressors. Each input is equipped with an LED that is lit when the input is active. These LEDs are not visible from the front panel.
WhyChoose Yokogawa Automation Limited
In order to show users that it attaches importance to the reliability, safety, and forward-looking attitude of system products, Yokogawa proposed the corporate philosophy of VigilantPlant. In the measurement field, it proposes solutions for analysis, quality management, sensors, and operation; in the control field Including production control, safety management, as well as data collection and logic control; optimization areas include production management, advanced control, asset management, and operation support. Following this corporate philosophy, Yokogawa uses cutting-edge technology to continuously develop new products and strive to make greater contributions to the industrialized society.
