Yokogawa SED2D-11 Module New In Stock
Overview
The output board UTK-2 is used for controlling external relays, e.g. for fans and fire doors. The UTK-2 board is controlled by the alarm processor board LPK-2, via the address and data buses in the back plane. The UTK-2 board is equipped with 24 opto-isolated outputs for 24 VDC/50 mA. The outputs are divided into six groups where each group includes four outputs and a common positive conductor.
The DC/DC circuit converts the battery voltage of the back plane to 5 VDC, which is supplied to all logical circuits on the board. Should the voltage disappear, a signal is activated in the back-plane.
The battery voltage is fused. If the fuse is blown a signal is activated in the back-plane. The fuse is accessible on the front panel of the board, and can be used for disconnecting the power.
On the front panel are two green LEDs for indicating 5V power and normal polling.
The address bus, the data bus and the control signals are buffered before entering the board.
The value written to the outputs can be read, to check the function of the board.
The output latches also functions as drive circuits for the opto switches.
s The outputs are divided into six groups, where each group has a common positive conductor. The load is connected between the output and ground. Each output is protected by a varistor and a freewheel diode for inductive loads.
