Triconex MP/IOP Backplane 7400207-001 New In Stock
Bus Systems and Power Distribution
Three triplicated bus systems are etched on the chassis backplane: the TriBus, the I/O bus and the communication bus. The TriBus consists of three independent serial links which operate at 25 megabits per second. The TriBus synchronizes the main processors at the beginning of a scan. Then each main processor sends its data to its upstream and downstream neighbors.
Tricon I/O Modules
115 VAC/VDC Opto-Isolated, Non-Commoned TMR 3501E/3501T48 VAC/VDC Commoned in Groups of 8, Self-Test TMR 3502E
24 VAC/VDC Commoned in Groups of 8, Self-Test TMR 3503E
24/48 VDC High Density, DC Coupled TMR 3504E
115 VAC Opto-Isolated, Non-commoned TMR 3601E/3601T
120 VDC Opto-Isolated, Non-commoned Opto-Isolated, Commoned TMR 3603B, 3603E/3603T
24 VDC Opto-Isolated, Non-commoned TMR 3604E
48 VDC Opto-Isolated, Non-commoned TMR 3607E
115 VAC Galvanically Isolated, Commoned., Supv. TMR 3611E
48 VDC Galvanically Isolated, Commoned, Supv. TMR 3617E
120 VDC Opto-Isolated, Commoned, Supervised 3623/3623T
0-5 VDC Differential, DC Coupled TMR 3700A
0-10 VDC Differential, DC Coupled TMR 3701
0-5, 0-10 VDC Differential, Isolated TMR 3703E
0-5, 0-10 VDC High-Density, Differential, DC Coupled TMR 3704E
Thermocouple Differential, DC Coupled TMR 3706A
4-20 mA Current Loop, DC Coupled TMR 3805E
4-20 mA and 20-320 mA Current Loop, DC Coupled TMR 3806E
