Siemens 6DD3460-0AC0SIMADYN D PULSE SENSOR BOARD
Description
SIMATIC operator panels are connected to MPI through the CS7 communication module and the SS52 communication module. Several operator panels can be operated on the MPI bus. The user programs the function and display of the operator panels using the ProTool/ Lite SIMATIC tool. This means, for example, that several process quantities can be monitored and changed. Commands can be entered, the SIMADYN D clock time can be set and displayed using function keys. Operating and fault messages can be defined in the OP using the user data areaHigh-performance serial couplings are implemented (PROFIBUS DP, Industrial Ethernet, fiber-optic cable subrack coupling) using the communication modules (CS..) and the communication sub-modules which can be inserted on them. It is important to especially mention the CS7 carrier module. Up to three communication modules, type SS4 (for DUST/USS protocols) or SS52 (for PROFIBUS DP) can be plugged-onto the CS7. A SIMOLINK master interface ITSL is directly plugged onto one of the CPU modules.
