Modicon Quantum ModuleBMXAMI0410Schneider New In Box

Introduction

The BMXAMI0410 is part of the Modicon X80 module series. It features 4 isolated analog inputs (16 bits) and is designed for use with sensors or transmitters. The module connects via a 20-way removable terminal block and performs monitoring, measurement, and process control functions for continuous processes1.
Technical Specifications:

1. Analog input quantity: 4
2. Analog input types: Current +/- 20 mA, 0-20 mA, 4-20 mA; Voltage +/- 10 V, +/- 5 V, 0-10 V, 0-5 V, 1-5 V
3. Analog-to-digital conversion: 24 bits
4. Input impedance: 10 MΩ (voltage mode), 250 Ω + 3.6…50 Ohm internal protective resistor (current mode)
5. Filter type: First-order digital filter
6. Fast read cycle: 1 ms + 1 ms per used channel
7. Measurement accuracy: <= 0.1% full scale (varies with input type and temperature)
8. Isolation voltage: 300 V DC channel-to-channel, 1400 V DC channel-to-ground, 1400 V DC channel-to-bus
9. LED status indicators: Green (RUN) for each channel, Red (ERR) for diagnostics
10. Weight: 0.143 kg
11. IP rating: IP20
12. Certifications: CE, RCM, CSA, EAC, UL
13. RoHS compliant, REACh compliant, Green Premium label
