Rockwell ICS TriplexTrusted T8123Processor Interface Adaptor

Product Overview

The Trusted Fan Tray 24 Vdc Rack Mounted comprises four fans mounted vertically at the rear of a 2U high chassis. The chassis containing the fans incorporates a baffle to prevent air drawn by the fans flowing through the module chassis immediately above the Fan Tray. Air exhausted by the fans into the rear of the system cabinet is drawn upwards and out of the cabinet by roof-mounted fans – see PD-T8271.The Fan Tray is powered from dual 24 Vdc supplies arranged such that the fans are supplied in pairs via 250 mA anti-surge fuses. The 0 V supply is connected via terminal block TB1. Each fan is capable of moving 69 m3/h when operating with a nominal rotor speed of 3100 rpm. Protection against overloading and reverse polarity is provided electronically for each fan

The main supply for the Fan Tray is derived from a Trusted Power Distribution Unit MCB 24 Vdc - T8292 via a Trusted Fan Power Cable – TC-011-01. The same type of cable is used to interconnect the Fan Trays/Roof Fans in a Trusted System module rack. A fully populated module rack will include five Fan Trays, and may also include a Roof Fan Unit. This is the maximum number of Fan Trays/Roof Fan Units that may be powered from a single Trusted Power Distribution Unit miniature circuit breaker (MCB).

Features:

• Simple installation and connection.

• Capable of moving 69 m3/h (40.6 ft3/min).

• 24 Vdc operation.

• Low noise (32 dB per fan)

• Supports up to three Trusted Sourcing Output Modules.

• Dual stud power connection for either single or dual feed.

• 0 V module reference via BLZ 2-part connectors.
