HONEYWELL 900A16-0001 OUTPUT MODULE 16 CHANNEL ANALOG HI LEVEL

Description

Manufacturer : Honeywell

Product No. :900A16-0001

Product type :OUTPUT MODULE 16 CHANNEL ANALOG HI LEVEL

Introduction

ATTENTION: RTP and cables are intended for permanent installation within their own enclosure. Mount RTP cable assembly to 900 Platform

-Remove appropriate key tabs from terminal block to allow mating with the module. For more details refer to the Installation and User manual (51-52-25-154).

-Connect desired cable to AO module at IO rack. Choose from: 900RTC-L210 Remote Terminal Low Voltage Cable Assembly, 1.0 meters long 900RTC-L225 Remote Terminal Low Voltage Cable Assembly, 2.5 meters long 900RTC-L250 Remote Terminal Low Voltage Cable Assembly, 5.0 meters long

-Install AO module label onto the module connector cover.

-Connect shield drain wire to the grounding bars at the base of the IO rack. All field-wiring shields must be grounded. For more details on shields grounding, refer to the section “Shield Grounding” in the Installation and User manual (51-52-25-154).
