Honeywell 8C-TDODA1Digital 0utput Module

Digital 0utput ModuleIntroduction

The Digital Output Module (DOM) is the heart of the Honeywell Voice Alarm and Public Address system. Managing either 8 or 24 zones the DOM routes up to 4 channels of audio via amplifiers to any individual zone or groups of zones. The 2 variants, DOM4-8 and DOM4-24 are both equipped with four independent audio outputs in order to access four channels. Each audio channel controls up to 8 loudspeakezones with each DOM managing 8 zones (DOM 4-8) or 24 zones (DOM 4-24). The loudspeaker circuits are constantly monitored for shortcircuit, earth fault and failure as well as for impedance deviation. Defective loudspeaker zones are isolated with the operation of all other zones unaffected. The system can accommodate either impedance or end of line monitoring providing a flexible solution to both new build and existing retrofit projects regardlessl of the type of loudspeakers currently installed.

The DOM has a 4-Port Fast-Ethernet-Switch for communication with other system components (DOM, SCU). The maximum range according to the norm with a CAT 5 cable is 90 m (plus 2 x 10 m patch cable). Increased operating distance/range and networking over fibre optics is possible with standard ethernet media converters.

Related Honeywell PLC modules

Honeywell RHMUX Remote FTA MC-GRMT01
Honeywell Digital Output 120/240 Vac Solid-State FTA MU-TDOA13 MC-TDOA13
Honeywell Digital Output 3-30 Vdc Solid-State FTA MU-TDOD13 MC-TDOD13
Honeywell Digital Output 3-30 Vdc Solid-State FTA MU-TDOD14 MC-TDOD14
Honeywell Digital Output 31-200 Vdc Solid-State MU-TDOD23 MC-TDOD23
Honeywell Digital Output 24 Vdc, 100 ma Nonisolated FTA MU-TDON12 MC-TDON12
Honeywell Digital Output 120 Vac/125 Vdc Relay FTA MU-TDOR12 MC-TDOR12
Honeywell Digital Output 240 Vac/125 Vdc Relay FTA MU-TDOR22 MC-TDOR22
Honeywell Digital Output 24 Vdc FTA MU-PDOY22 MU-TDOY22 MC-TDOY22
Honeywell Digital Output Relay FTA MU-PDOY22 MU-TDOY23 MC-TDOY23
