Honeywell MC-TAIH62 High Level Analog InputNew In Stock

Description

Remote I/O options are available to enable IOPs and FTAs to be distributed at up to six remote sites (see Figure 5). Using redundant fiber-optic cables to extend the I/O Link, remote I/O installation benefits from inherent immunity against ground potential differences and EMI/RFI. In addition, remote installation of IOPs and FTAs can significantly reduce signal wire runs. Two options are available. The Remote I/O option supports remote sites up to 1 kilometer from the main PM/APM/HPM/EHPM electronics, while the Long Distance I/O option provides for separation of up to 8 kilometers. Either option requires an I/O link Extender pair (IOLE) at both ends. The 1-km option supports up to three remote sites for each IOLE, while the 8-km option requires one IOLE per remote site. FTAs at the remote site may be located an additional 50 meters from the I/O Processors. LLAI Mux, Serial Device, or Serial Interface FTAs may be located an additional 300 meters away. The RHMUX FTA may be located an additional 2 km away.

Packaging & Shipping

1.All the goods will be tested before shipment.
2.Packing in professional anti-static bag.
3.We can ship to you by DHL/TNT/UPS/EMS/Fedex...Pls contact us directly and we will ship as your requirement.
