Honeywell 8C-TAIX61 Module C300 System
Overview
The C300 Controller may operate in both non-redundant and redundant configurations. Redundant operation requires a second identical controller and connecting cables, which is the typical configuration. The switchover time from the active primary controller to the backup controller of a redundant pair is less than 500 milliseconds.
When a C300 Controller block is added to the Project tree in Control Builder, a graphic representation of a controller module and its resident function blocks appears as shown in Figure 2. The function blocks that are contained in the controller support multiple execution environments. A Control Execution Environment block (CEEC300) and two IOLINK blocks are contained in the controller and appear under the controller. When the controller block is configured as redundant, the secondary controller block is added in the Project tree.
The C300 Controller supports three Execution Environment (EE) function blocks. One is the Control EE block, (CEEC300). The other two are I/O Link blocks, (IOLINK). The IOLINK blocks in the C300 support connection and communication with all Series 8 I/O modules.
