Quality New Honeywell 8C-PAOHA1 51454469-275Module
Introduction
Each detected fault is reported by means of a diagnostic message, alarm markers and/or diagnostic markers. If the nature of the fault requires the system to respond, Safety Manager™ will isolate the faulty component from the rest of the system. At the same time the system acts on the effect of loosing the function of that component. That action may be: • none, a redundant component can cover for the lost function. • none, loosing the function has no impact on safety. • apply the fault reaction state to the affected IO. • start the repair timer. • halt the affected Control Processor. • de-energize all non-redundant outputs via the watchdog • de-energize all outputs via the watchdog. Below explains these items in more detail.
HoneywellField Termination Assemblies FTA Models
|
Uncoated Model Number |
Coated Model Number |
Description |
|
MU-TAIH22 |
MC-TAIH22 |
Enhanced Power High Level /STI Analog Input FTA (16 Inputs) ** |
|
MU-TAIH02 |
MC-TAIH02 |
High Level Analog Input/STI FTA (16 Inputs) |
|
MU-TAIH12 |
MC-TAIH12 |
High Level Analog Input/STI FTA for Redundancy (16 Inputs) ** |
|
MU-TAIH03 |
MC-TAIH03 |
High Level Analog Input FTA (16 Inputs) (CE Mark) |
|
MU-TAIH13 |
MC-TAIH13 |
High Level Analog Input FTA for Redundancy (16 Inputs) (CE Mark) ** |
|
MU-TSTX03 |
MC-TSTX03 |
Smart Transmitter Interface FTA (16 Inputs) (CE Mark) |
|
MU-TSTX13 |
MC-TSTX13 |
Smart Transmitter Interface FTA for Redundancy (16 Inputs) (CE Mark) ** |
|
MU-TAIH23 |
MC-TAIH23 |
Enhanced Power High Level Analog Input FTA (16 Inputs) (CE Mark)** |
Original And New
| 1771-NC6 | CI810B | 900G01-0102 |
| 1771-NC15 | CI810B 3BSE020520R1 | 900C75-0360-00 |
| 1771-IXHR | CI830 | 900C73R-0100-44 |
| 1771-IR | CI830 3BSE013252R1 | 900C73R-0100-43 |
| 1771-IMD | CI840A 3BSE041882R1 | 900C72R-0100-44 |
| 1771-IL | CI853K01 3BSE018103R1 | 900C72R-0100-43 |
| 1771-IK | CI854AK01 | 900C72-0144-00 |
| 1771-IFM | CI854AK01 3BSE030220R1 | 900C53-0244-00 |
| 1771-IFEK | CI855K01 3BSE018106R1 | 900C53-0124-00 |
| 1771-IFE | CI857K01 3BSE018144R1 | 900C53-0001 51500189-0012 |
| 1771-IBN/C | CI858K01 3BSE018135R1 | 900C52-0244-00 |
| 1771-IB | CI860 CI860K01 3BSE032444R1 | 900C52-0001 |
| 1771-IAN | CM30/000S0E0/STD | 900C51-0001 |
| 1771-IAD | CM572-DP 1SAP170200R0001 | 900C50-0360-00 |
