Fast Delivery100% Original Honeywell51199188-100 Module

Introduction

Features Type: XS831 Auxiliary Terminal Package  For mounting onto the top and/or bottom of alreadyinstalled XF830A mixed I/O modules and the top of already-installed XFU830A and CPO-IO830 mixed I/O modules in order to equip them with additional terminals. Two groups of four pairs of push-in terminals (A1B1, A2B2, … A8B8, each with a 499Ω resistor) for converting 0…20 mA signals (max. load per resistor = 25 mA) into 0…10 VDC signals, and one push-in ground terminal per group. See also Fig. 63 and Fig. 64. NOTE: The ground side of each of the eight incoming 0…20 mA signals (A1B1, A2B2, … A8B8) must be connected to a ground terminal.

The LONWORKS Bus is a 78-kilobit serial link that uses transformer isolation so that the bus wiring does not have a polarity. I.e. it is not important which of the two LONWORKS Bus terminals are connected to each wire of the twisted pair. The shield of the LONWORKS Bus must not be connected to any part of the controller. When connecting the LonWorks Bus via the RJ45 interface, use an isolated plastic plug. The LONWORKS Bus can be wired in daisy chain, star, loop or any combination thereof as long as the max. wire length requirements are met.

We focus on Honeywell DCSSystem Experion PKS ( C200 , C300 )FSC

1. Control Processor, TK-PRR021, CC-PCNT01 51405046-175, TC-PRS021, TK-PRS021, CC-PFB801, CC-PFB401, 8C-PAIH51, 8C-PAOHA1

2. Fault Tolerant Ethernet Bridge ( FTEB ), TK-FTEB01 51309512-175, FC-TPSU-2430, FC-TSGAS-1624, FC-DCOM-232/485, FC-TSAI-1620M, FC-SAI-1620M, FC-SDI-1624

3. Controlnet Interface ( CNI ) , FC-TPSU-2430, FC-TSGAS-1624, FC-DCOM-232/485, FC-TSAI-1620M, FC-SAI-1620M, FC-SDI-1624

4. Redundancy Module ( RM ) TC-PRR021 51309288-225, TK-PRS021 51404305-375, TK-PRR021 51309288-275, TC-IXR061 96978373

5. IOLIM ( I/O Link Interface Module )TC-IAH16I, TC-OAV081, TC-IXR061, TC-ODD321, TC-IAH161, TC-IXL061, TK-PRR021

6. PM I/OCards, TK-IOLI01 51403427-275, CC-TAIX01 51308363-175, CC-TAOX01 51308351-175, 8C-TDODA1 51307149-175, TK- IOLI01 51403427-275

7. FTACards, MC-TAIH02 51304453-150 UCN, MC-TDOY22 51204162-175 UCN, MC-TDIY22 51204160-175 UCN, MC-TAOY22 51204172-175 UNC, MC-PAIH03 51304754-150

8. FSC Module, 10024/H/F, 10020/1/2, 10018/E/1, 10101/2/1, 10004/H/F, 10105/2/1, 10201/2/1, 10001/R/1, 10006/2/1

9. UCN BOARD, 80363969-150 ( MC-PAOY22 ), 51309276-150, 51309355-001, 51304516-250, 51304754-150, MC-PAIH03, 51305430-100

You Might be Interested

Packaging & Shipping
1.All the goods will be tested before shipment.
2.Packing in professional anti-static bag.
3.We can ship to you by DHL/TNT/UPS/EMS/Fedex...Pls contact us directly and we will ship as your requirement.

About Us

Servo module Parts Limitedfor many years, is a professional engaged in large-scale system (distributed control system, programmable controller, redundant fault-tolerant control systems, robot control system, large servo control system is the central feeding system plastic molding auxiliary equipment and automation of whole plant planning) imported automation system such as spare parts, modules, sales and system integration of high-tech enterprises. The company is equipped with professional technicians to provide customers with better service.
