honeywell LL112007 Discrete output terminal panel

Introduction

The Honeywell 8C-TDIL11 is a redundant, isolated, high-speed digital input module for use in Honeywell Experion PKS control systems. It is designed to accept 24VDC signals from a variety of field devices, such as switches, sensors, and transmitters. The module features extensive internal diagnostics for data integrity, open wire detection, and optional redundancy. It also has internal or external field power selection, on-board excitation power, and supplies non-incendive field power.
Features
Redundant design for increased system reliability
Isolated inputs to protect against ground faults and noise
High-speed inputs for fast response times
Extensive internal diagnostics for data integrity
Open wire detection to identify faulty field devices
Optional redundancy for added protection
Internal or external field power selection for flexibility
On-board excitation power for powering field devices
Supplies non-incendive field power for safety in hazardous areas
Direct/reverse input indication for easy troubleshooting
Galvanic isolation to protect against electrical interference
Technical Specifications
Input type: High-impedance, differential voltage, optically isolated (1000 VDC)
Input voltage range: -25V to +25V
Input current: 0.5 mA maximum
Input impedance: 100 MΩ minimum
Frequency range:
0 - 100 KHz Single Channel
0 – 10 KHz Dual Pulse Channel
Frequency accuracy ( 0.5 Hz – 100 KHz): +/- 0.001% of Reading
Input voltage (Independent of Input Voltage Range):
24 VDC nominal
18 VDC to 30 VDC operating range
Power consumption: 2.5 watts maximum
Operating temperature: -40°C to +70°C
Storage temperature: -40°C to +85°C
Humidity: 0% to 95% non-condensing
Vibration: 0.05g RMS, 5 to 500 Hz
Shock: 15g, 20 msec half-sine
Dimensions: 6 inches x 12 inches x 1.2 inches
Weight: 2 pounds

We focus on Honeywell DCSSystem Experion PKS ( C200 , C300 )FSC

1. Control Processor, TK-PRR021, CC-PCNT01 51405046-175, TC-PRS021, TK-PRS021, CC-PFB801, CC-PFB401, 8C-PAIH51, 8C-PAOHA1

2. Fault Tolerant Ethernet Bridge ( FTEB ), TK-FTEB01 51309512-175, FC-TPSU-2430, FC-TSGAS-1624, FC-DCOM-232/485, FC-TSAI-1620M, FC-SAI-1620M, FC-SDI-1624

3. Controlnet Interface ( CNI ) , FC-TPSU-2430, FC-TSGAS-1624, FC-DCOM-232/485, FC-TSAI-1620M, FC-SAI-1620M, FC-SDI-1624

4. Redundancy Module ( RM ) TC-PRR021 51309288-225, TK-PRS021 51404305-375, TK-PRR021 51309288-275, TC-IXR061 96978373

5. IOLIM ( I/O Link Interface Module )TC-IAH16I, TC-OAV081, TC-IXR061, TC-ODD321, TC-IAH161, TC-IXL061, TK-PRR021

6. PM I/OCards, TK-IOLI01 51403427-275, CC-TAIX01 51308363-175, CC-TAOX01 51308351-175, 8C-TDODA1 51307149-175, TK- IOLI01 51403427-275

7. FTACards, MC-TAIH02 51304453-150 UCN, MC-TDOY22 51204162-175 UCN, MC-TDIY22 51204160-175 UCN, MC-TAOY22 51204172-175 UNC, MC-PAIH03 51304754-150

8. FSC Module, 10024/H/F, 10020/1/2, 10018/E/1, 10101/2/1, 10004/H/F, 10105/2/1, 10201/2/1, 10001/R/1, 10006/2/1

9. UCN BOARD, 80363969-150 ( MC-PAOY22 ), 51309276-150, 51309355-001, 51304516-250, 51304754-150, MC-PAIH03, 51305430-100
