New original DCS Module SPS5710 51199929-100 In Stock

Description

The Honeywell SPS5710 is a 24VDC power supply module that is designed for use in Honeywell TDC 3000 control systems. It is a DIN-rail mountable power supply that provides 20A of continuous output current and 24V of regulated DC voltage. The SPS5710 is a high-efficiency power supply that has an input voltage range of 100-240VAC and a frequency range of 47-63Hz. It is also a fault-tolerant power supply that has overvoltage, overcurrent, and short circuit protection.
Features
24VDC output voltage
20A continuous output current
100-240VAC input voltage range
47-63Hz input frequency range
High efficiency
Overvoltage, overcurrent, and short circuit protection
DIN-rail mountable
Technical Specifications
Specification Value
Output voltage 24VDC
Output current 20A continuous
Input voltage range 100-240VAC
Input frequency range 47-63Hz
Efficiency >85%
Operating temperature range -20 to +70°C
Storage temperature range -40 to +85°C
Humidity 0 to 95% non-condensing
Vibration 0.5g RMS, 5 to 500Hz
Shock 5g, 20ms half-sine
MTBF >50,000 hours
Dimensions 127 x 45 x 112mm
Weight 2.15kg
