FTA-E-01 Honeywell HART Analog Output Module

Product Description

The Honeywell FTA-E-01 is a fail-safe digital input FTA (Functional Safety Application) designed for use in safety applications in industrial automation systems. It provides 24 channels of digital input that can be used to monitor safety-related devices such as emergency stop switches, limit switches, and safety sensors. The FTA-E-01 is designed to meet the requirements of IEC 61508 SIL 2 and is suitable for use in a wide range of safety applications.
Features
24 channels of digital input
Fail-safe design
Meets IEC 61508 SIL 2 requirements
Wide operating temperature range
DIN rail mounting
LED status indicators
Technical Specifications
Input voltage: 24/48/60 VDC
Input current: ≤ 2 mA per channel
Output voltage: 24 VDC
Output current: ≤ 100 mA per channel
Operating temperature: -20 to +70 °C
Storage temperature: -40 to +85 °C
Humidity: 5 to 95% RH, non-condensing
Vibration: 5 g RMS, 10 to 500 Hz
Shock: 15 g, 11 ms
MTBF: > 100 years
MTTR: < 2 hours

Note

Previous versions of this power supply had five terminals on the terminal block. The new version (shown above), which has six terminals, is functionally the same as the previous version. The change was made to conform to European EC requirements.
