Original New Honeywell TK-FXX102 Redundant Power System Chassis Adaptor
Features
The Redundant Power Supply System is designed with the following features:
1.Current Sharing Control between each supply – for maximum power supply life
2.Error Detection – for maximum security
3.Error Annunciation – for immediate notification
4.LED Indication – indicating redundant, non-redundant, and failure conditions
Specifications
| Model | TC-FPCXX2 | TC-FPDXX2 |
| Model | TK-FPCXX2 | TK-FPDXX2 |
| Input Voltage Range |
85-132 VAC or 170-265 VAC (selectable) |
19.2-32 VDC1 |
| Input Power2 | 150 VA, 92 W | 100 W |
| Maximum Inrush Current | 15 A | 30 A |
| Frequency Range | 47-63 Hz | DC |
| Total power output maximum, watts | 70 W @ 60C | 70 W @ 60C |
| Backplane Output Current, Maximum3 | 1.5 A @ 1.2 V, 4 A @ 3.3 V, 10 A @ 5.1 V, 2.8 A @ 24.0 V | |
| Fuse Protection4 | non-replaceable fuse is soldered in place | |
| Wiring | #14 AWG (1.4 mm) | |
| Dimensions (L x D x H) | 11.2 x 14.5 x 14.0 cm (4.41 x 5.71 x 5.51 in) | |
| Weight – Approximate | 1.1 kg (2.5 lb.) | |
| Location | Left side of chassis (does not consume a slot) |
Honeywell DCSSystem Experion PKS C200
Honeywell MC-TDOY22 Digital Output 3-30 Vdc Solid-State FTA (16 Outputs)
Honeywell MC-TDOD13 Digital Output Relay FTA (16 Outputs) (use two w/ MU-PDOY22)
Honeywell MC-TDOY23 Digital Input 24 Vdc FTA (32 Inputs)
Honeywell MC-TDID12 Digital Output 240 Vac/125 Vdc Relay FTA (16 Outputs)
Honeywell MC-TDOR22 51309150-175 High Level Analog Input
Honeywell MC-TDOR22HLAI/STI Redundant Smart Trans mitter Interface Process
Honeywell MU-TAIH12 AO Redundant Analog Output (8 Outputs)
Honeywell MU-TAIH12Analog Output FTA for Redundancy (8 Outputs)
Honeywell MU-TAOX12 FTA Model，Low Level Analog InputFTA (8 Inputs)
Honeywell MU-TAIL02 Div 2 interfacing Enhanced Power High Level /STI Analog Input FTA (16 Inputs)
Honeywell MU-TAIH22 Pulse Input FTA (8 Inputs)
Honeywell MU-TPIX12 High Level Analog Input/STI FTA (16 Inputs) Resistor Current Limited, 145
Honeywell MU-TAIH02 Digital Input 24 Vdc FTA (32 Inputs)
Honeywell MU-TDID12 53104441-100 Digital Input 24 Vdc FTA -Packaged, without plug-in isolators (32 Inputs)
Honeywell MU-TDID72 51303928-100 Digital Input 24 Vdc FTA (32 Inputs)
Honeywell MU-TDID12 51304441-125 Digital Output 3-30 Vdc Solid-State FTA (16 Outputs)
Honeywell MU-TDOD13
