Foxboro FBM202 P0914ST I/A Series Channel Isolated 8 Input Module

FBM202 P0914ST Introduction

The FBM202P0914STThermocouple/mV Input Interface contains eight thermocouple input channels, and one isolated RTD reference junction compensation channel (for terminal temperature sensing). Each thermocouple/mV channel accepts standard thermocouples for various temperature ranges, and each provides thermocouple burnout detection (up-scale). TheFBM202P0914STinputs are galvanically isolated from other channels and ground. TheFBM202P0914STmodule performs the signal conversion required to interface the electrical input signals from the field sensors to the optionally redundant Fieldbus.

Application Areas

Additional Similar Product

FBM247 TA Compact FBM201 TA Compact FBM202 TA Compact FBM203 TA Compact FBM203c TA Compact FBM203d TA Compact FBM204 TA Compact FBM207 TA Compact FBM207b TA Compact FBM207c TA Compact FBM208 TA Compact FBM211 TA Compact FBM212 TA Compact FBM214b TA Compact FBM215 TA Compact FBM216b TA Compact FBM217 TA Compact FBM218 TA Compact FBM219 TA Compact FBM227 TA Compact

Foxboro Analog Inputs Module

Eight Analog Inputs connect to eight DeltaV 4-20mA AI CHARMs – FBM model number FBM201/P916AA

Four Analog Inputs connect to four DeltaV 4-20mA AI CHARMs– FBM model numbers FBM204/P0916AG, FBM205/P0916AJ

Fourteen Analog Inputs connect to fourteen DeltaV Thermocouple/mV CHARMs – FBM model number FBM212/P0916BV

Eight Analog Inputs connect to eight DeltaV RTD CHARMs – FBM model number FBM203/P0916AE

Eight Analog Thermocouple/mV inputs connect to eight DeltaV Thermocouple/mV CHARMs – FBM model number FBM202/P0916AC
