Foxboro I/A Series P0914WM Module FBM241c

Output Owner Priority Structure

Output Mode With FoxCom transmitters, specify your output as Digital or Analog. Specify Analog if you want an analog 4 to 20 mA signal. In this mode, a 600 baud digital signal is superimposed over the 4 to 20 mA signal for communication with a PC-Based Configurator. Specify Digital if you want to have a 4800 baud digital signal for I/A Series system communication. If you selected Digital on your FoxCom transmitter or with a fieldbus transmitter, specify Unidirectional (UniDir) or BiDirectional (BiDir) flow. If you want a pulse output, you must specify Unidirectional. The default setting is UniDir.

The IMT25 can provide digital measurement values, an analog output, and a pulse output. Each of these output signals usually reflects the live process measurement. However, under special circumstances, a higher priority “owner” can control these outputs. For example, the AutoZeroLock Detector or the manual Signal Lock function can lock all of the outputs to the Zero flow condition. Alternately, you can manually preset (or override) each of the outputs. Similarly, diagnostic and alarm conditions can cause the analog and pulse outputs to be forced to the configured “failure” setting. In addition, the analog and pulse outputs are forced to the Zero flow condition when the transmitter is taken off-line for configuration using the optional keypad/display. Also, the analog output is frozen at 4.0 mA if the transmitter is configured for multi-drop operation of the HART communications output.

FAQ:

1.Is the part new?
Yes, 100% Original brand new

2.How is the package?
Original factory seal packed

3.What is the lead time?
In stock: 1-3 working days

4.What is the MOQ:
1pcs

5.What is the payment term:
TT and Western Union, other negotiable

6.Where the item ship from?

Xiamen

7.What is the warranty time?
One year

8. How to delivery the PLC Parts?
Kindly tell us your address,we check best cost for you
Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
