Brand New And Original Foxboro FBM216 P0922VVModule

Description

The Foxboro FBM216 P0922VV is a redundant 8-channel analog input module that is part of the I/A Series system. It is designed to connect to field devices such as pressure or temperature transmitters that use the 4-20mA current loop for signal transmission. The FBM216 P0922VV supports HART communication, which allows the system to request and receive two digital messages per second from each field device. This provides more detailed information about the field device, such as its calibration status and diagnostic information.
The FBM216 P0922VV is a redundant module, which means that it has two independent channels for each input. This ensures that the system will continue to operate even if one of the channels fails. The module also has a built-in self-diagnostic system that can detect and report faults.

Features
Eight isolated analog input channels
Supports any mix of standard 4-20mA devices and HART devices
HART communication
Redundant design
Built-in self-diagnostic system

Technical Specifications
Input channels: 8
Input signal range: 4-20mA
Accuracy: ±0.075% of full scale
Resolution: 15 bits
Update rate: 100 milliseconds
Integration time: 500 milliseconds
Common mode rejection: >100 dB at 50 or 60 Hz
Normal mode rejection: >35 dB at 50 or 60 Hz
Communication protocol: HART
Communication speed: 1200 baud
Maximum distance: 3030 meters (10000 feet)
Power supply: 24V DC
Power consumption: 10W
Operating temperature: -40 to 80°C (-40 to 176°F)
Storage temperature: -40 to 85°C (-40 to 185°F)
Humidity: 0 to 95% non-condensing
Vibration: 0.05g RMS, 20 to 500 Hz
Shock: 15g, 20 milliseconds
Dimensions: 14 mm (H) x 45 mm (L) x 104 mm (D)
Weight: 0.5 kg
Approvals: CE, RoHS

FAQ:
1.Is the part new?
Yes, 100% Original brand new
2.How is the package?
Original factory seal packed
3.What is the lead time?
In stock: 1-3 working days
4.What is the MOQ:
1pcs
5.What is the payment term:
TT and Western Union, other negotiable
6.Where the item ship from?
Xiamen
7.What is the warranty time?
One year

8. How to delivery the PLC Parts?
Kindly tell us your address,we check best cost for you
Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.

Packaging & Shipping
1.All the goods will be tested before shipment.
2.Packing in professional anti-static bag.
3.We can ship to you by DHL/TNT/UPS/EMS/Fedex...Pls contact us directly and we will ship as your requirement.
