Foxboro Module FBM232 P0926GW

Overview

The Foxboro FBM232 P0926GW Ethernet Communication Module is a single Ethernet interface between single-ported field I/O devices and the Foxboro Evo™ system. It provides a cost-effective and reliable solution for integrating field devices into a Foxboro Evo control system.

Features

1. Single 10/100 Mbps Ethernet port
2. Supports up to 64 field devices
3. Communicates with a wide variety of I/O block types
4. Integrates field device data into a Foxboro Evo control database
5. Field mounted
6. Class G3 (harsh) environments

1. Power Requirements: 24 VDC, 1.0 A
2. Power Consumption: 24 W
3. Operating Temperature: -40 to 70°C (-40 to 158°F)
4. Storage Temperature: -40 to 85°C (-40 to 185°F)
5. Humidity: 0 to 95% non-condensing
6. Vibration: 0.03 g RMS, 20 to 500 Hz
7. Shock: 5 g, 20 ms half-sine pulse
8. Dimensions: 102 mm x 45 mm x 104 mm (4.02 in x 1.77 in x 4.09 in)
9. Weight: 284 g (10 oz)
