Foxboro Module FEM100

Overview

The Foxboro FEM100 is a Fieldbus Expansion Module that provides four additional Expanded Fieldbuses to an I/A Series FCP270 controller. This allows the FCP270 to support a larger number of 200 Series (or equivalent) Fieldbus Modules (FBMs). The FEM100 communicates with the FBMs using the 2 Mbps HDLC protocol.

The FEM100 also supports a variety of communication protocols, including Modbus, IEC 60870-5-101/104, DNP3.0, IEC 61850, and Ethernet/IP. This makes it easy to integrate the FEM100 into existing systems.

Features

• Adds four Expanded Fieldbuses to an I/A Series FCP270 controller
• Supports 200 Series (or equivalent) Fieldbus Modules (FBMs)
• Communicates with FBMs using the 2 Mbps HDLC protocol
• Supports Modbus, IEC 60870-5-101/104, DNP3.0, IEC 61850, and Ethernet/IP communication protocols
• Rugged and reliable design
• Easy to install and maintain

1. Power requirements: 24 VDC, 500 mA
2. Operating temperature: -40 to 80°C (-40 to 176°F)
3. Humidity: 0 to 95% non-condensing
4. Vibration: 0.05 g RMS, 5 to 500 Hz
5. Shock: 5 g, 20 ms half-sine
6. Dimensions: 6.81 in (173 mm) x 4.06 in (103 mm) x 1.97 in (50 mm)
7. Weight: 2.2 lb (1.0 kg)
