EMERSON EPRO A6740/12 Supply Brand New

Description

The EPRO A6740/12 provides 16 independent relay outputs to activate alarms, shutdowns, or control external devices based on machine health data from the AMS 6500 system. Each relay can be configured for normally open or normally closed operation, and can be energized or de-energized based on a variety of logic conditions. The module also features a time delay function for each relay.
Features:
16 independent relay outputs
Normally open or normally closed operation
Energized or de-energized based on logic conditions
Time delay function for each relay
Redundant relay configuration
Off, AND, OR, 2 out of 3, AND AND OR logic
Up to 30 logic expressions definable per 6740 module
60 inputs of the following types:
Channel clear (slot number), channel 1 and 2
Alert (slot number), channel 1 and 2
Danger (slot number), channel 1 and 2
Technical Specifications:
Control voltage: 13-32 VDC
Contact load: 48 V, 1 A
Logic inputs: 60 inputs
Relay outputs: 16 relays
Time delay: 0 - 30 seconds
Dimensions: Width: 60mm (2.362in) (12 TE); Height: 128.4mm (5.055in) (3 HE); Length: 160mm (6.300in)
Net Weight: approximately 320g (0.705lbs)
