GE Bently Nevada 330180-91-05 Proximity for 3300 XL 8 mm Proximitor Transducer System

Overview

The 3300 XL 8 mm Proximity Transducer System consists of:

One 3300 XL 8 mm probe, one 3300 XL extension cable, and one 3300 XL Proximitor* Sensor

The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor* reference and speed measurements3. The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-metre system also fully complies with the American Petroleum Institute’s (API) 670 Standard (4th Edition) for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components.

Features

The 3300 XL Proximitor Sensor incorporates numerous improvements over previous designs. Its physical packaging allows you to use it in high-density DINrail installations. You can also mount the sensor in a traditional panel mount configuration, where it shares an identical 4-hole mounting “footprint” with older Proximitor Sensor designs. The mounting base for either option provides electrical isolation and eliminates the need for separate isolator plates. The 3300 XL Proximitor Sensor is highly immune to radio frequency interference, allowing you to install it in fiberglass housings without adverse effects from nearby radio frequency signals. The 3300 XL Proximitor Sensor’s improved RFI/EMI immunity satisfies European CE mark approvals without requiring special shielded conduit or metallic housings, resulting in lower installation costs and complexity.

Specifications

Bently Nevada 3500 Series in Stock

3500/05, 3500/06, 3500/08, 3500/15, 3500/20, 3500/22M , 3500/25, 3500/32, 3500/33, 3500/34, 3500/40M, 3500/42, 3500/65 184469-01,3500/44M, 3500/45, 3500/46, 3500/50, 3500/53, 3500/60, 3500/61, 3500/62, 3500/64M, 3500/65,3500/70M, 3500/60, 3500/65,3500/72M,3500/77M,3500/90, 3500/33,3500/33 149992-01,3500/33 149986-01, 3500/53, 3500/53 133388-01, 3500/53 133396-01,3500/65 184522-01, 3500/92, 3500/92 136180-01, 3500/92(136180-01), 3500/15 125840-01, 3500/15 133300-01, 3500/15 127610-01
