Bently Nevada 3500/50M 286566-02 Display System Module

Keyphasor Module

The 3500/25 is a halfheight module that provides power and termination for up to two Keyphasor transducers. When applications require one or two Keyphasor transducers, simply install a single 3500/25 module. The 3500 System can accommodate up to four Keyphasor transducers per rack by installing two 3500/25 Keyphasor modules in the rack. When two 3500/25 Keyphasor modules are used, they must be installed in the same rack slot, one above the other. Keyphasor signals from the 3500/25 module(s) can be routed to appropriate monitor modules via the 3500’s rack backplane for use in speed, phase, tracking filter, and other measurements

Multiple communication gateway modules can be installed in a rack when the system requires redundant communication or must support multiple communication protocols simultaneously. The modules do not interfere with the 3500 System’s normal operations or machinery protection functions, ensuring that the monitoring system integrity is always maintained, even in the unlikely event of a Communication Gateway module failure.
