Bently Nevada 125720-01 Relay Output Module

Description

The 4-Channel Relay Module is a full-height module that provides four relay outputs.125720-01Any number of 4-Channel Relay Modules can be placed in any of the slots to the right of the Rack Interface Module.125720-01Each output of the 4- Channel Relay Module can be independently programmed to perform needed voting logic.

Each relay utilized on the 4-Channel Relay Module includes "Alarm Drive Logic". The Alarm Drive Logic is programmed using AND and OR logic,125720-01and can utilize alarming inputs (alerts and dangers) from any monitor channel or any combination of monitor channels in the rack. This Alarm Drive Logic is programmed using the 3500 Rack Configuration Software to meet the specific needs of the application.

Note

Triple Modular Redundant (TMR) applications require the use of the 3500/34 TMR Relay Module. Consult Bently Nevada Specification and Ordering.
