Bently Nevada 3500 Position I/O Module 135145-01

Description

The 135145-01 Position Monitor is a 4-channel monitor that accepts input from proximity transducers, Rotary Position Transducers (RPTs), DC Linear Variable Differential Transformers (DC LVDTs), AC Linear Variable Differential Transformers (AC LVDTs), and rotary potentiometers.

It conditions these inputs and compares the conditioned signals with userprogrammable alarms. The 3500 Configuration Software can program each channel of the 3500/45 to perform any of the following functions:

-Axial (thrust) Position

-Differential Expansion

-Standard Single Ramp Differential Expansion

-Non-standard Single Ramp Differential Expansion

-Dual Ramp Differential Expansion

-Complementary Differential Expansion

-Case Expansion

-Valve Position

Each channel, depending on configuration, typically conditions its input signal into various parameters called “proportional values”. Alert setpoints can be configured for each active proportional value and Danger setpoints can be configured for any two of the active proportional values.
