Bachmann CNT204/R 00010709-20 PLC CNT204/xCounter Function Modules
Features
The counter module CNT204/x contains four counters for single line pulse generators. Two of the channels can optionally be used as inputs for incremental encoders.
1.4 counter inputs for single line pulse generators
2.Status indication: LED (green) per counter/ initiator input
3.2 input channels for incremental encoders
4.Encoder power supply directly from the module via the connectors
5.Inputs can be synchronized
6.Monitoring of all supply voltages
7.Period measurement with 42 ns resolution
8.Differential measurement (phase shift between C1 and C3 or C2 and C4) with 42 ns resolution
CNT204/x Specification
| Part No. | CNT204/R | ||
| Order No. | 00010709-20 | ||
| Inputs Quantity | 2 | ||
| Counter resolution | 32 bit | ||
| Input signals | A-, A+ / B-, B+ / N-, N+ | ||
| Signal evaluation | 1- /2- /4-edge evaluation or pulse direction mode | ||
| Max. input frequency | 1 MHz (RS422) /300 kHz (HTL) | ||
| Input filter | 185 kHz to 6 MHz adjustable, default 6 MHz |
CNT204/x Counter Modulesin Stock
CNT204/R 00010709-20 Counter module; 2x INC RS422 1MHz + 2x counter HTL 20kHz
CNT204/H 00010709-10 Counter module; 2x INC HTL 300kHz + 2x counter HTL 20kHZ
CNT204/H CC 00016407-10 Like CNT204/H; ColdClimate
KZ-CNT204 B 00012057-30 Terminal set Phoenix cage clamp (1x KZ 51/02; 1x KZ 51/12) with labeling strip
SV-CNT204 B 00010869-50 Terminal set Phoenix screw frontside (1x SV 51/02; 1x SV 51/12) with labeling strip
