ABB Bailey NTDI21-A Brand New

Module Description The digital input module consists of a single printed circuit board that occupies one slot in a module mounting unit. It monitors two separate groups of eight digital inputs. Twelve inputs are isolated from each other; the remaining two pairs share common positive input lines.

Two captive screws on the module faceplate secure it to the module mounting unit. Sixteen front panel LED status indicators (group A and group B) display the input status and provide aid in system test and diagnosis.

The digital input module has three card edge connectors for external signals and power (P1, P2 and P3). P1 connects to common (ground) and +5 VDC power. P2 connects the module to the I/O expander bus to communicate with a controller. P3 inputs the digital signals using a cable connected to a termination unit. The terminal blocks (physical connection points) for field wiring are on the termination unit.
