ABBSBRC300 Bailey Infi 90

Introduction

This manual provides technical information required for the physical connection of the Previse OPC Server/Driver to the Bailey Net 90 or INFI 90 DCS. This manual includes:

- Instructions for module set up for communications with Driver.

-Description of known communications limitations where applicable This manual does not include:

-Instructions for installation or general configuration of modules.

Description

The Communication Termination Unit (NTCL01) provides a termination point for a Network Interface Slave Module (INNIS01) or a Loop Interface Module (INLIM03). The TCL gives the option of using twinaxial or coaxial cable to connect the NIS to the INFI-NET communication network or the LIM to Plant Loop. Jumper settings on the TCL select the type communication cable.Technicians should read the manual before installing and operating the TCL. Do not put the TCL into operation until you read and understand this instruction.
