ABB AO820 3BSE008546R1 Analog Output Module

Information

The AO820 Analog Output Module has 4 bipolar analog outputchannels. The choice of current or voltage output is configurable for

each channel. There are separate sets of terminals for voltage andcurrent outputs, and it is up to the user to wire outputs properly. The
only differences between current or voltage channel configuration isin software settings.

To supervise the communication to the A/D-converters the outputdata is read back and verified. The opencircuit diagnostics are read
continuously as well. The process voltage supervision input givechannel error signals if the voltage disappears. The error signal can
be read via the ModuleBus.

Features and benefits

-8 channels of 0...20 mA, 4...20 mA outputs
-OSP sets outputs to predetermined state upon error detection
-Analog Output is to be short circuit secured to ZP or +24 V
-Process and power connection via detachable connectors
