ABB Bailey INFI 90 INIIT13 Transfer Module New In Box

Description

The INIIT13Sequence of Events Timing module processes up to 16 digital field inputs, and receives and decodes the time synchronization link information sent by the INIIT13 module for a Harmony controller. The controller utilizes function code 241 (DSOE data interface) to interface SOE data from the INIIT13 module to the INIIT13 module, and function code 242 (SOE digital event interface) to configure and access theINIIT13module input channels. Each channel is optically isolated, and can be individually programmed for 24 VDC, 48 VDC, 125 VDC, and 120 VAC input. The module communicates with its Harmony controller over I/O expander bus. Only one IMSET01 module can operate on an I/O expander bus segment. The module cable connects toINIIT13and NTDI01 termination units. The INIIT13 unit provides for time synchronization link termination. The NTDI01 unit provides for field wiring termination.

The INIIT13module monitors Harmony control units for data on an exception report basis, collects and sorts data it acquires, and provides SOE data to human system interfaces for report presentation after some predefined trigger condition occurs. Digital state transitions are collected at the HCU level by INIIT13and vbmodules, then forwarded to theINIIT13 module. The INIIT13module records the information and sorts it according to time in an internal database. When a trigger condition occurs, the human system interface is notified and data transfer occurs.
