ABBIMASI03 INFI 90 Analog Input Module

Description

The Universal Analog Input Slave Module (IMASI03) interfaces field inputs to the multi-function processor module. The IMASI03 supplies 16 separate process field signals into the INFI 90® Process Management System. These analog inputs are used by the Multi-Function Processor Module (MFP) to monitor and control a process. Universal analog input slave modules provide an isolated thermocouple, millivolt, RTD, and high level analog signal interface for the Multi-Function Processor Module with variable analog-to-digital conversion resolution up to a maximum of 24 bits. This instruction explains the slave module features, specifications and operation. It details the procedures to set up and install an IMASI03 module, and explains status indicators that help in system test and diagnosis. System engineers or technicians using the IMASI03 should read and understand this instruction before installing and operating the slave module. In addition, a complete understanding of the INFI 90 system is beneficial to the user.

ABB In Stock
