ABBBailey Controls IMMFP01 INFI 90 Multi-Function Processor Module
Description
The IMMFP01 Multi-Function Processor Module has four configurable dipswitches, one socket and five jumpers. Each dipswitch has eight positions. shows the location of dipswitches and jumpers on the multi-function processor (MFP) circuit board. Dipswitch UUB0 sets the module address, bus speed and operation mode (normal/diagnostic). Dipswitch UMB1 sets module options and enables special operations. Tables through list the dipswitch setting descriptions. The HW SETUP socket defines the number of SRAM banks installed and selects wait states for ROM, NVRAM and SRAM. Table B-7 shows the jumper settings for the HW SETUP socket
