ABB Bailey IMSET01 Sequence of Event Time Keeper Module

Description

The Distributed Sequence of Events (SOE) provides a fully integrated system approach to event monitoring, recording and reporting for the Symphony Enterprise Management and Control System. Digital input transitions are collected and time-stamped at the time of occurrence. All input detection modules are time-synchronized, and coordinated through an external time input (e.g., satellite receiver system (SRS)). This event input data is passed over the network to the INSOE01, Sequence of Events Server Node which is responsible for collecting and sorting event data coming from distributed Harmony control units (HCU). This stored event data is made available to the human system interface for report generation.

The IMSET01 and IMSED01 modules perform two functions: The acquisition of the 16 digital inputs from the field. The synchronization of their internal clocks. The IMSET01 module receives the time information from the time-sync link and keeps the internal clocks synchronized with this time. The two modules are controlled by the controller, and communicate across the I/O expander bus. The controller keeps the IMSED01 modules synchronized by reading the time from the IMSET01 module and writing it to the IMSED01 modules with a broadcast messag
