ABB 100% Original New NTMF01 In Stock

Overview

The NTMF01 Multi-Function Controller Termination Unit (TMF) terminates two RS-232-C ports for the IMMFC03 Multi-Function Controller, INICT01 INFI-NET to Computer Transfer Module, INPPT01 Plant Loop to Plant Loop Transfer Module and INPCT01 Plant Loop to Computer Transfer Module. When terminating an IMMFC03 module (or redundant IMMFC03 modules), it enables the IMMFC03 module to communicate to a computer, terminal, printer or sequential events recorder through the serial ports (see Figure 1-1). It also provides a serial link for an NDCS03 Digital Control Station or IISAC01 Analog Control Station through an NTCS04 Control I/ O Termination Unit. The IMMFC04 and IMMFC05 Multi-Function Controllers use the NTMF01 termination unit to terminate a station link an7d connect to a redundant controller. The INICT01 INFI-NET to Computer Interface Module is part of the INICI01 INFI-NET to Computer Interface.

The INPCT01 Plant Loop to Computer Interface Module is part of the INPCI02 Plant Loop to Computer Interface. Figure 1-2 shows an example Plant Loop to computer interface application. The two modules use the TMF termination unit to terminate the connection of a mainframe, computer, terminal or modem to the INFI-NET or Plant Loop communication networks respectively. The INPPT01 Plant Loop to Plant Loop Transfer Module is part of an INPPR01 Plant Loop to Plant Loop Remote Interface. Figure 1-3 shows an example Plant Loop to Plant Loop interface module application. Each PPT (one local, one remote) module connects to the other through the NTMF01 termination unit.
